The device is equipped with 4 on-board low current relays that support a voltage range of 6-30V and can handle currents up to 5A. It includes 1 power output with a maximum current of 500mA. Utilizing Speed-X technology, it supports expander cascading with 1 uplink Speed-X port for control panel connection and 1 downlink Speed-X port for connecting the next expander. The hardware features also include 1 TTL serial port and tamper-proof protection at both the front and rear. The device operates within a power supply range of 11 to 24 VDC, with a typical voltage of 12 VDC. It has a maximum power consumption of 153 mA at 12 VDC and a quiescent current of 70 mA at 12 VDC. The output current is capped at 500 mA, and the output voltage ranges from 9 to 12 VDC.
| Feature | Specification |
|---|---|
| On-board Low Current Relays | 4 (supporting 6-30V, up to 5A current) |
| Power Output | 1 (maximum 500mA) |
| Technology | Speed-X (supporting expander cascading) |
| Speed-X Ports | 1 uplink, 1 downlink |
| Serial Port | 1 TTL serial port |
| Tamper-Proof Protection | Support (front and rear) |
| Bus | 2×Speed-X (1 uplink, 1 downlink) |
| Power Supply Range | 11 to 24 VDC |
| Typical Voltage | 12 VDC |
| Power Consumption | Max: 153 mA@12 VDC, Quiescent: 70 mA@12 VDC |
| Output Current | Maximum 500 mA |
| Output Voltage | 9 to 12 VDC |
