The IS-6A Bronze Gate Valve is manufactured as per the IS-778 standard and falls under Class-2 pressure rating. The body of the valve is made from GM bronze (IS:318 Gr.LTB2). It features a screwed-in bonnet with an inside screw mechanism and a rising stem. The valve includes an integral seat and a solid wedge, with trim components made of Cu-Alloy. The gland packing is composed of PTFE. The end details are designed for flanges as per IS:778 Class-2 F.F. (Flat Face), undrilled.
| Specification | Details |
|---|---|
| Product Name | IS-6A Bronze Gate Valve |
| Product Standard | IS-778 |
| Pressure/Class/Rating | Class-2 |
| Body Material | GM (IS:318 Gr.LTB2) |
| Description | Screwed in Bonnet, Inside Screw, Rising Stem |
| Type of Seat | Integral Seat |
| Type of Wedge | Solid Wedge |
| Trim | Cu-Alloy |
| Gland Packing | PTFE |
| End Details | Flanges as per IS:778 Class-2 F.F., undrilled |
