The IS-12 Bronze Globe Valve is a high-quality valve designed to meet IS-778 standards, classified under Class-2 pressure rating. It is constructed from gun metal (IS:318 Gr.LTB2), providing excellent durability and corrosion resistance. The valve features a screwed-in bonnet, an inside screw mechanism, and a rising stem, which ensures smooth operation and precise control. The integral seat enhances sealing performance, while the Cu-Alloy trim ensures robust performance. The valve is packed with PTFE gland packing to prevent leakage. It is designed with flanges as per IS:778 Class-2 F.F. undrilled, making it versatile for various applications.
Table Form:
| Specification | Details |
|---|---|
| Product Name | Bronze Globe Valve |
| Product Standard | IS-778 |
| Pressure/Class/Rating | Class-2 |
| Body Material | GM (IS:318 Gr.LTB2) |
| Description | Screwed in Bonnet, Inside Screw, Rising Stem |
| Type of Seat | Integral Seat |
| Trim | Cu-Alloy |
| Gland Packing | PTFE |
| End Details | Flanges as per IS:778 Class-2 F.F. undrilled |
