Boring Machine Frequency Converter Fan-3112KL-05W-B60

model: 3112KL-05W-B60
Voltage: 24 V
Noise: 44 dB

SKU: AFT0001

Original price was: SAR 72.00.Current price is: SAR 60.00.

model: 3112KL-05W-B60
Voltage: 24 V
Noise: 44 dB

ENQUIRY!

Compare

Add to wishlist

17 People watching this product now!

[product_acf_field]

Payment Methods:

Description

This high-performance fan is designed to maintain optimal cooling for boring machine frequency converters, ensuring efficient and reliable operation. The fan is built with robust materials and advanced engineering to deliver excellent airflow and static pressure while operating at low noise levels. Designed to last up to 50,000 hours at 25°C (L10), reducing the need for frequent replacements. Consumes only 5W of power, making it an energy-efficient cooling solution.

Attribute	Specification
Frame Width	80 mm
Frame Height	80 mm
Frame Depth	32 mm
Max. Air Flow	58.6 CFM (1.66 m³/min)
Max. Static Pressure	0.32 In H2O (78.9 Pa)
Fan Speed	4350 RPM
Noise	44 dB
Life Expectancy at 25°C	50,000 Hours (L10)
Bearing Type	Ball Bearing
Nominal Voltage	24 V
Operating Voltage – Lower	10 V
Operating Voltage – Upper	25.2 V
Current	0.21 A
Input Power	5 W
Mass	95 g
Tach / Locked Rotor Output	No
Status	Active
