The SFP 500-31 EM centrifugal fire pump is designed for end suction applications with a top centerline discharge. It features a foot-supported casing and a back pullout design for easy maintenance. The pump incorporates a self-venting design to prevent air lock and ensure smooth operation. Its efficiently designed impeller enhances performance efficiency, while the frame-mounted design ensures stability and durability, making it suitable for retrofitting in spaces with limited room. The pump is constructed with heavy-duty materials including cast iron or ductile iron casing, and offers options for bronze or duplex impellers and alloy steel, stainless steel, or duplex shafts upon request. It has a capacity range from 50 to 1000 GPM, operating at pressures from 65 to 234 PSI with a maximum working pressure of 180 to 315 PSI. Available in speeds of 2900, 3000, 3500, and 3600 RPM, it meets stringent industry standards with 100% hydrostatic and performance testing.
| Feature | Description |
|---|---|
| Type | Centrifugal Fire Pump |
| Configuration | End Suction, Top Centerline Discharge |
| Casing | Foot Supported, Back Pullout Design, Self-Venting Design |
| Impeller | Efficiently Designed |
| Mounting | Frame-Mounted |
| Footprint | Small, Ideal for Retrofit |
| Construction Materials | Casing: Cast Iron / Ductile Iron |
| Impeller: Bronze / Duplex (upon request) | |
| Shaft: Alloy Steel / Stainless Steel / Duplex (upon request) | |
| Capacity | 50 to 1000 GPM |
| Pressure | 65 to 234 PSI |
| Max. Working Pressure | 180 to 315 PSI |
| Speed | 2900, 3000, 3500, 3600 RPM |
| Model | SFP 500-31 EM |
| Rated Capacity (GPM) | 500 |
| Flange Size (Suc x Dis) | 5 x 3 in |
| UL Listed | No |
| Rated Net Pressure Range | 129 – 217 PSI |
| Approx Speed (RPM) | 2900 |
| Max Working Pressure (PSI) | 315 |
