The NW8000A-2 is a conventional fire alarm control panel designed to support multiple zones, allowing for flexible fire detection coverage. It can manage 1, 2, 4, or 8 zones, making it adaptable to various building sizes and requirements. Powered by an AC input of 220-230V and providing a DC output of 27V, the panel ensures stable performance. It uses two 12V/1.3Ah backup batteries, which offer reliable power in case of outages. Each zone can connect up to 20 smoke or heat detectors, maximizing detection efficiency. The system includes a 6.8kΩ end-of-line resistor for maintaining electrical circuit integrity. The panel supports a siren output with a maximum current of 400mA, ensuring audible alerts when necessary. Housed in a durable iron casing, the NW8000A-2 measures 275mm x 200mm x 72.5mm and weighs 2.3kg (excluding batteries), making it a compact and sturdy choice for fire alarm systems.
| Feature | Specification |
|---|---|
| Model | NW8000A-2 |
| Zone Numbers | 1, 2, 4, 8 zones |
| AC Input | 220V~230V |
| DC Output | 27V DC |
| Battery Type | 2 x 12V/1.3Ah |
| Max Detectors per Zone | 20 pcs (Smoke/Heat detectors) |
| End of Line Resistor | 6.8kΩ |
| Siren Output | Available |
| Max Output Current | 400mA |
| Dimensions (L x W x H) | 275mm x 200mm x 72.5mm |
| Body Material | Iron |
| Weight (without battery) | 2.3kg |
