The switch features 12 gigabit PoE ports, 4 gigabit Hi-PoE ports, 2 gigabit RJ45 ports, and 2 gigabit fiber optical ports. It complies with IEEE standards including 802.3at/af/bt for Hi-PoE ports (max. 90 W PoE output) and 802.3at/af for PoE ports (max. 30 W PoE output). Surge protection of 6 kV is provided for PoE ports, and the switch supports up to 300 m long-range transmission. It includes a PoE watchdog to auto-detect and restart unresponsive cameras, port isolation for enhanced network security, and a gigabit network access design with wire-speed forwarding and store-and-forward switching. The switch is housed in a solid high-strength metal shell.
| Feature | Description |
|---|---|
| Ports | 12 × gigabit PoE ports, 4 × gigabit Hi-PoE ports, 2 × gigabit RJ45 ports, 2 × gigabit fiber optical ports |
| Hi-PoE Port Standard | IEEE 802.3at/af/bt (Max. 90 W PoE output) |
| PoE Port Standard | IEEE 802.3at/af (Max. 30 W PoE output) |
| Other Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, IEEE 802.3z |
| Surge Protection | 6 kV for PoE ports |
| Transmission Range | Up to 300 meters |
| PoE Watchdog | Auto detects and restarts unresponsive cameras |
| Port Isolation | Improves network security |
| Design | Gigabit network access design, wire-speed forwarding, store-and-forward switching |
| Shell | Metal material |
| Weight | Net Weight: 2.79 kg (6.15 lb), Gross Weight: 3.60 kg (7.94 lb) |
| Dimensions | 440.0 mm × 44.0 mm × 220.8 mm (17.3” × 1.7” × 8.7”) |
| Operating Temperature | 0 °C to 45 °C (32 °F to 113 °F) |
| Storage Temperature | -40 °C to 85 °C (-40 °F to 185 °F) |
| Operating Humidity | 5% to 95% (no condensation) |
| Relative Humidity | 5% to 95% (no condensation) |
| Power Supply | 100~240 VAC, 50/60 Hz, Max. 4 A |
